SELECT GENERATION

MAN-23

Title

MAN-23

Title

MAN-24

Title

MAN-24

Title

MAN-25

Title

MAN-25

Title

MAN-26

Title

MAN-26

Title

SPECIFICATION

50 HP

POWER

273.6 kg

MASS

POWERTRAIN

CHASSIS

SUSPENSION

AERODYNAMICS

ELECTRONICS

MAN-23

Title

Title

SPECIFICATION

56 HP

POWER

249.5 kg

MASS

POWERTRAIN

  • New SLS printed intake

  • New custom rocker cover to integrate new ECU

  • New laser cut and welded oil sump

  • New catch cans

  • New SLS printed intake

  • New custom rocker cover to integrate new ECU

  • New laser cut and welded oil sump

  • New catch cans

CHASSIS

  • Steel spaceframe

  • New steering mount

  • Custom IA attempted

  • Steel spaceframe

  • New steering mount

  • Custom IA attempted

SUSPENSION

  • Steel double wishbone suspension

  • New Fox X2 dampers

  • Carbon wishbones

  • Reused front and rear wheel assemblies

  • Steel double wishbone suspension

  • New Fox X2 dampers

  • Carbon wishbones

  • Reused front and rear wheel assemblies

AERODYNAMICS

  • Full aerodynamics package developed

  • Underfloor, front wing, rear wing,nosecone

  • Full aerodynamics package developed

  • Underfloor, front wing, rear wing,nosecone

ELECTRONICS

  • New Cosworth Badenia data logger implemented

  • Completely new

  • New Cosworth Badenia data logger implemented

  • Completely new

MAN-24

Title

Title

SPECIFICATION

76kW

POWER

255.2 kg

MASS

POWERTRAIN

  • Emrax 208 motor with DTI HV500 inverter

  • Accumulator with 112s7p VTC6 cells

  • Aluminium accumulator housing

  • Chain drive with mechanical differential

  • Emrax 208 motor with DTI HV500 inverter

  • Accumulator with 112s7p VTC6 cells

  • Aluminium accumulator housing

  • Chain drive with mechanical differential

CHASSIS

  • Steel spaceframe

  • New aluminium pedal box

  • Steel spaceframe

  • New aluminium pedal box

SUSPENSION

  • Steel double wishbone suspension

  • Reused front and rear uprights

  • Steel double wishbone suspension

  • Reused front and rear uprights

AERODYNAMICS

  • No aerodynamics developed to enable full focus on EV powertrain

  • New lighter CFRP nosecone

  • No aerodynamics developed to enable full focus on EV powertrain

  • New lighter CFRP nosecone

ELECTRONICS

  • Self developed VCU and BMS system

  • Self developed VCU and BMS system

MAN-25

Title

Title

SPECIFICATION

80 HP

POWER

228.5 KG

MASS

POWERTRAIN

  • Brand new SLS printed intake and redesigned stainless steel 4-2-1 exhaust

  • Redesigned CNC milled wet sump

  • Reworked fuel tank

  • Brand new SLS printed intake and redesigned stainless steel 4-2-1 exhaust

  • Redesigned CNC milled wet sump

  • Reworked fuel tank

CHASSIS

  • Steel spaceframe with new aluminium rear bulkhead

  • Expanding foam seat formed to driver's body with custom-made fire-rated cover

  • Steel spaceframe with new aluminium rear bulkhead

  • Expanding foam seat formed to driver's body with custom-made fire-rated cover

SUSPENSION

  • Steel double wishbone suspension

  • Brand new front wheel assembly (uprights & wheel hubs)

  • Steel double wishbone suspension

  • Brand new front wheel assembly (uprights & wheel hubs)

AERODYNAMICS

  • CFRP nosecone

  • Remaining package removed due to manufacturing issues

  • CFRP nosecone

  • Remaining package removed due to manufacturing issues

ELECTRONICS

  • Fully integrated CAN system with extensive instrumentation

  • Brand new panel dashboard

  • Fully integrated CAN system with extensive instrumentation

  • Brand new panel dashboard

MAN-26

Title

Title

RESULTS

44TH

FSUK OVERALL

25TH

UK TEAM RANK

MAN-23

Title

Title

RESULTS

38TH

FSUK OVERALL

29TH

UK TEAM RANK

MAN-24

Title

Title

RESULTS

37TH

FSUK OVERALL

28TH

UK TEAM RANK

MAN-25

Title

Title

RESULTS

12TH

FSUK OVERALL

7TH

UK TEAM RANK

MAN-26
